COOLING PIPING (#1006-)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
5
2
16
10
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 154-03-71260 | [1] | Hose Komatsu | 1.7 кг. |
| ["SN: 1006-UP"] | ||||
| 2. | 07289-00080 | [4] | Clamp Komatsu | 0.064 кг. |
| ["SN: 1006-UP"] analogs:["2050961120", "690106C1"] | ||||
| 3. | 09483-40309 | [1] | Hose Komatsu | 0.194 кг. |
| ["SN: 1006-UP"] | ||||
| 4. | 154-03-71770 | [2] | Cover Komatsu China | |
| ["SN: 1006-UP"] | ||||
| 5. | 07281-00197 | [2] | Clamp Komatsu | 0.015 кг. |
| ["SN: 1006-UP"] analogs:["1950313250"] | ||||
| 6. | 08034-20536 | [2] | Band Komatsu | 0.003 кг. |
| ["SN: 1006-UP"] | ||||
| 7. | 154-03-71290 | [1] | Tube Komatsu China | |
| ["SN: 1006-UP"] | ||||
| 8. | 07000-63045 | [1] | O-ring Komatsu OEM | 0.003 кг. |
| ["SN: 1006-UP"] | ||||
| 9. | 154-03-71280 | [1] | Hose Komatsu | 0.28 кг. |
| ["SN: 1006-UP"] | ||||
| 10. | 07289-00055 | [4] | Clamp Komatsu | 0.058 кг. |
| ["SN: 1006-UP"] analogs:["802660176"] | ||||
| 11. | 01010-81235 | [2] | Bolt Komatsu | 0.048 кг. |
| ["SN: 1006-UP"] analogs:["0101051235", "01010E1235", "801015136"] | ||||
| 12. | 01643-31232 | [2] | Washer Komatsu | 0.027 кг. |
| ["SN: 1006-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 13. | 154-03-71270 | [1] | Tube Komatsu China | |
| ["SN: 1006-UP"] | ||||
| 14. | 07000-62060 | [1] | O-ring Komatsu | 0.02 кг. |
| ["SN: 1006-UP"] analogs:["0700072060", "6217515670"] | ||||
| 15. | 154-03-71780 | [1] | Hose Komatsu | 1.06 кг. |
| ["SN: 1006-UP"] | ||||
| 19. | 154-03-71711 | [1] | Tube Komatsu | 2.15 кг. |
| ["SN: 1006-UP"] | ||||
| 20. | 154-03-31571 | [1] | Gasket Komatsu | 0.01 кг. |
| ["SN: 1006-UP"] | ||||
| 21. | 01010-81035 | [4] | Bolt Komatsu | 0.033 кг. |
| ["SN: 1006-UP"] analogs:["801015556", "01010D1035", "0101051035"] | ||||
| 22. | 01643-31032 | [4] | Washer Komatsu | 0.054 кг. |
| ["SN: 1006-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] | ||||
| 23. | 07042-30108 | [1] | Plug Komatsu | 0.008 кг. |
| ["SN: 1006-UP"] analogs:["0704220108"] | ||||
| 24. | 07042-70415 | [1] | Plug Komatsu | 0.056 кг. |
| ["SN: 1006-UP"] | ||||
