HYDRAULIC OIL COOLER PIPING, RETURN PIPING, OIL COOLER (#1006-)
1
2
3
4
5
6
7
8
9
10
11
15
16
17
18
19
20
21
22
23
24
25
26
27
28
3
23
14
13
12
19
18
6
8
2
1
7
19
18
3
5
3
4
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 02762-00637 | [1] | Hose Komatsu China | |
| ["SN: 1006-UP"] | ||||
| 2. | 02762-00640 | [1] | Hose, Face Seal Type Komatsu China | 3.14 кг. |
| ["SN: 1006-UP"] | ||||
| 3. | 02762-00444 | [2] | Hose, Face Seal Type Komatsu | 1.84 кг. |
| ["SN: 1006-UP"] | ||||
| 4. | 20Y-62-22810 | [2] | Band, Yellow Komatsu | 0.001 кг. |
| ["SN: 1006-UP"] | ||||
| 5. | 20Y-62-22820 | [2] | Band, Blue Komatsu | 0.01 кг. |
| ["SN: 1006-UP"] | ||||
| 6. | 20Y-62-22840 | [2] | Band, Black Komatsu | 0.001 кг. |
| ["SN: 1006-UP"] | ||||
| 7. | 02896-11012 | [2] | O-ring Komatsu China | 0.17 кг. |
| ["SN: 1006-UP"] analogs:["855051014"] | ||||
| 8. | 02896-11018 | [2] | O-ring Komatsu | 0.24 кг. |
| ["SN: 1006-UP"] analogs:["855051018", "R0289611018"] | ||||
| 9. | 20Y-62-15950 | [2] | Clip Komatsu | 0.05 кг. |
| ["SN: 1006-UP"] | ||||
| 10. | 01010-81230 | [2] | Bolt Komatsu | 0.043 кг. |
| ["SN: 1006-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 11. | 01643-31232 | [2] | Washer Komatsu | 0.027 кг. |
| ["SN: 1006-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 12. | 04434-52512 | [1] | Clip Komatsu | 0.034 кг. |
| ["SN: 1006-UP"] | ||||
| 15. | 04435-52512 | [1] | Clip Komatsu China | |
| ["SN: 1006-UP"] | ||||
| 17. | 20Y-62-15960 | [4] | Clip Komatsu | 0.06 кг. |
| ["SN: 1006-UP"] | ||||
| 20. | 154-03-71990 | [1] | Bracket Komatsu China | |
| ["SN: 1006-UP"] | ||||
| 23. | 20Y-62-17930 | [2] | Clip Komatsu China | |
| ["SN: 1006-UP"] | ||||
