ENGINE MOUNTING, AIR CLEANER SENSOR (#65001-)
16
17
18
21
21
24
27
19
20
22
25
1
1
5
8
10
2
3
9
2
13
2
2
2
2
2
6
3
3
12
14
6
2
3
26
23
4
4
15
7
4
7
4
11
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 209-01-41460 | [1] | Hose Komatsu | 0.85 кг. |
| ["SN: 65001-UP"] | ||||
| 2. | 04434-51412 | [8] | Clip Komatsu | 0.02 кг. |
| ["SN: 65001-UP"] | ||||
| 3. | 01010-81225 | [6] | Bolt Komatsu | 0.074 кг. |
| ["SN: 65001-UP"] analogs:["01010B1225", "0101051225", "0101051222", "R0101081225"] | ||||
| 4. | 01643-31232 | [6] | Washer Komatsu | 0.027 кг. |
| ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 5. | 04434-51410 | [1] | Clip Komatsu | 0.018 кг. |
| ["SN: 65001-UP"] | ||||
| 6. | 01010-81020 | [2] | Bolt Komatsu | 0.161 кг. |
| ["SN: 65001-UP"] analogs:["801014093", "0101051020", "801015108"] | ||||
| 7. | 01643-31032 | [2] | Washer Komatsu | 0.054 кг. |
| ["SN: 65001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] | ||||
| 8. | 209-04-77140 | [1] | Plate Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 9. | 195-06-41930 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 12. | 04434-53412 | [1] | Clip Komatsu | 0.044 кг. |
| ["SN: 65001-UP"] | ||||
| 13. | 175-40-22540 | [1] | Spacer Komatsu | 0.15 кг. |
| ["SN: 65001-UP"] | ||||
| 14. | 01010-81275 | [1] | Bolt Komatsu | 0.082 кг. |
| ["SN: 65001-UP"] analogs:["0101051275"] | ||||
| 16. | 209-01-41710 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 17. | 01010-81230 | [2] | Bolt Komatsu | 0.043 кг. |
| ["SN: 65001-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 19. | 7861-93-1422 | [1] | Sensor Komatsu | 0.000 кг. |
| ["SN: 65015-UP"] | ||||
| 19. | 7861-93-1421 | [1] | Sensor Komatsu | 0.1 кг. |
| ["SN: 65001-65014"] analogs:["7861931420", "20Y0642910"] | ||||
| 20. | 08037-02512 | [1] | Grommet Komatsu | 0.02 кг. |
| ["SN: 65001-UP"] | ||||
| 21. | 04434-51012 | [2] | Clip Komatsu | 0.014 кг. |
| ["SN: 65001-UP"] | ||||
| 24. | 08193-20012 | [1] | Clip Komatsu | 0.012 кг. |
| ["SN: 65001-UP"] | ||||
| 27. | 08034-20536 | [1] | Band Komatsu | 0.003 кг. |
| ["SN: 65001-UP"] | ||||
