COOLING SYSTEM, INNER PARTS, FAN MOTOR (1/3) (#65001-) PC800-8E0 S/N 65001-UP Komatsu


OK. Запрос отправлен.
EXCAVATORS
PC800-8E0 S/N 65001-UP
COOLING SYSTEM, WITHOUT AIR CONDITIONER
COOLING SYSTEM, FAN MOUNTING (#65001-)
COOLING SYSTEM, FAN MOUNTING (#65001-)
c002006
COOLING SYSTEM, RADIATOR AND OIL COOLER MOUNTING (#65048-)
COOLING SYSTEM, RADIATOR AND OIL COOLER MOUNTING (#65048-)
c002005
COOLING SYSTEM, RADIATOR AND OIL COOLER MOUNTING (#65001-65047)
COOLING SYSTEM, RADIATOR AND OIL COOLER MOUNTING (#65001-65047)
c002004
COOLING SYSTEM, INNER PARTS, FAN MOTOR (2/3) (#65001-)
COOLING SYSTEM, INNER PARTS, FAN MOTOR (2/3) (#65001-)
c002008
COOLING SYSTEM, INNER PARTS, FAN MOTOR (3/3) (#65001-)
COOLING SYSTEM, INNER PARTS, FAN MOTOR (3/3) (#65001-)
c002009
COOLING SYSTEM, FAN MOTOR RELATED PARTS (#65001-)
COOLING SYSTEM, FAN MOTOR RELATED PARTS (#65001-)
c002010

COOLING SYSTEM, INNER PARTS, FAN MOTOR (1/3) (#65001-)

PC800-8E0 S/N 65001-UP
2
3
4
5
6
7
8
9
10
11
12
13
14
15
17
21
22
23
16
18
19
20
12
3
16
1
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
     708-7W-00130   [1]   Motor Assembly Komatsu 38.003 кг.
    ["SN: 65001-UP"] |$0.
   1.   708-7W-11180   [1]   Case Komatsu China
    ["SN: 65001-UP", "SCC: C2"]
        708-7W-01050   [1]   Cover Subassembly Komatsu 6.5 кг.
    ["SN: 65001-UP", "SCC: C2"] |$2.
   4.   709-25-11650   [1]   Valve, Check Komatsu 0.02 кг.
    ["SN: 65001-UP", "SCC: C2"]
   5.   709-25-11361   [1]   Spring Komatsu 0.005 кг.
    ["SN: 65001-UP", "SCC: C2"]
   6.   708-7S-21610   [1]   Plug Komatsu China
    ["SN: 65001-UP", "SCC: C2"]
   7.   07002-22434   [1]   O-ring Komatsu 1.1 кг.
    ["SN: 65001-UP"] analogs:["0700232434", "R0700222434"]
   9.   708-7W-18150   [1]   Spring Komatsu China
    ["SN: 65001-UP", "SCC: C2"]
   10.   708-7W-18160   [1]   Spacer Komatsu China
    ["SN: 65001-UP", "SCC: C2"]
   11.   708-7W-18170   [1]   Cover Komatsu China
    ["SN: 65001-UP", "SCC: C2"]
   12.   07000-F2016   [2]   O-ring Komatsu 0.001 кг.
    ["SN: 65001-UP"] analogs:["0700022016"]
   13.   07000-F2035   [1]   O-ring Komatsu 0.001 кг.
    ["SN: 65001-UP"]
   14.   01252-60845   [4]   Bolt, Hexagon Socket Head Komatsu 0.025 кг.
    ["SN: 65001-UP"] analogs:["0125230845"]
   15.   07000-F2010   [1]   O-ring Komatsu 0.008 кг.
    ["SN: 65001-UP"] analogs:["0700022010"]
   16.   708-7W-01070   [1]   Valve Assembly, Pilot Komatsu China
    ["SN: 65001-UP"]
17.   01252-60616   [2]   Bolt, Hexagon Socket Head Komatsu 0.007 кг.
    ["SN: 65001-UP"] analogs:["0125230616"]
18.   708-7S-18360   [1]   O-ring Komatsu China
    ["SN: 65001-UP"]
19.   07000-F1008   [1]   O-ring Komatsu 0.001 кг.
    ["SN: 65001-UP"]
20.   708-7S-18230   [1]   O-ring Komatsu 0.001 кг.
    ["SN: 65001-UP"]
21.   07040-11007   [1]   Plug Komatsu 0.014 кг.
    ["SN: 65001-UP"]
22.   07002-21023   [1]   O-ring Komatsu 0.22 кг.
    ["SN: 65001-UP"]
   23.   01252-60835   [4]   Bolt, Hexagon Socket Head Komatsu 0.021 кг.
    ["SN: 65001-UP"]
