COOLING SYSTEM, INNER PARTS, FAN MOTOR (2/3) (#65001-) PC800-8E0 S/N 65001-UP Komatsu


OK. Запрос отправлен.
EXCAVATORS
PC800-8E0 S/N 65001-UP
COOLING SYSTEM, WITHOUT AIR CONDITIONER
COOLING SYSTEM, INNER PARTS, FAN MOTOR (1/3) (#65001-)
COOLING SYSTEM, INNER PARTS, FAN MOTOR (1/3) (#65001-)
c002007
COOLING SYSTEM, FAN MOUNTING (#65001-)
COOLING SYSTEM, FAN MOUNTING (#65001-)
c002006
COOLING SYSTEM, RADIATOR AND OIL COOLER MOUNTING (#65048-)
COOLING SYSTEM, RADIATOR AND OIL COOLER MOUNTING (#65048-)
c002005
COOLING SYSTEM, INNER PARTS, FAN MOTOR (3/3) (#65001-)
COOLING SYSTEM, INNER PARTS, FAN MOTOR (3/3) (#65001-)
c002009
COOLING SYSTEM, FAN MOTOR RELATED PARTS (#65001-)
COOLING SYSTEM, FAN MOTOR RELATED PARTS (#65001-)
c002010
COOLING SYSTEM, FAN MOTOR PIPING (#65001-65017)
COOLING SYSTEM, FAN MOTOR PIPING (#65001-65017)
c002011

COOLING SYSTEM, INNER PARTS, FAN MOTOR (2/3) (#65001-)

PC800-8E0 S/N 65001-UP
10
9
8
2
5
6
4
7
3
1
12
13
17
15
16
15
20
11
18
19
14
21
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
     708-7W-00130   [1]   Motor Assembly Komatsu 38.003 кг.
    ["SN: 65001-UP"] |$0.
   1.   708-7W-11920   [1]   O-ring Komatsu China
    ["SN: 65001-UP"]
   2.   04020-01024   [2]   Pin, Dowel Komatsu 0.015 кг.
    ["SN: 65001-UP"] analogs:["PZF890001197"]
   3.   01252-61480   [4]   Bolt Komatsu China
    ["SN: 65001-UP"]
   4.   708-7W-12130   [1]   Shaft Komatsu China
    ["SN: 65001-UP", "SCC: C2"]
   5.   708-7W-12140   [1]   Bearing Komatsu China
    ["SN: 65001-UP", "SCC: C2"]
   6.   708-7W-12150   [1]   Bearing Komatsu China
    ["SN: 65001-UP", "SCC: C2"]
   7.   708-7L-05010   [1]   Spacer Kit Komatsu 0.1 кг.
    ["SN: 65001-UP", "SCC: C2"]
   8.   708-25-52861   [1]   Seal, Oil Komatsu China 0.078 кг.
    ["SN: 65001-UP", "SCC: C2"] analogs:["7082552860", "7067340920"]
   9.   708-2L-22160   [1]   Spacer Komatsu 0.047 кг.
    ["SN: 65001-UP", "SCC: C2"]
   10.   04065-06825   [1]   Ring, Snap Komatsu 0.018 кг.
    ["SN: 65001-UP"]
   11.   708-8F-33121   [1]   Block, Cylinder Komatsu 4.1 кг.
    ["SN: 65001-UP", "SCC: C2"]
   12.   708-8F-33230   [1]   Plate, Valve Komatsu China
    ["SN: 65001-UP", "SCC: C2"]
   13.   720-68-19610   [1]   Pin Komatsu 0.002 кг.
    ["SN: 65001-UP", "SCC: C2"]
   14.   708-8F-33360   [3]   Pin Komatsu 0.006 кг.
    ["SN: 65001-UP", "SCC: C2"]
   15.   708-7L-13140   [2]   Seat Komatsu 0.02 кг.
    ["SN: 65001-UP", "SCC: C2"]
   16.   708-8F-33160   [1]   Spring Komatsu 0.153 кг.
    ["SN: 65001-UP", "SCC: C2"]
   17.   04065-04818   [1]   Ring, Snap Komatsu OEM 0.007 кг.
    ["SN: 65001-UP"]
   18.   708-8F-33350   [1]   Guide, Retainer Komatsu 0.135 кг.
    ["SN: 65001-UP", "SCC: C2"]
   19.   708-2L-33350   [1]   Retainer, Shoe, Shoe Komatsu 0.3 кг.
    ["SN: 65001-UP", "SCC: C2"]
   20.   708-8F-33310   [9]   Piston Subassembly Komatsu 0.204 кг.
    ["SN: 65001-UP", "SCC: C2"]
   21.   708-7F-13420   [1]   Plate, Thrust Komatsu China
    ["SN: 65001-UP", "SCC: C2"]
