COOLING SYSTEM, COVER AND SENSOR (#65001-) PC800-8E0 S/N 65001-UP Komatsu


OK. Запрос отправлен.
EXCAVATORS
PC800-8E0 S/N 65001-UP
COOLING SYSTEM, WITHOUT AIR CONDITIONER
COOLING SYSTEM, OIL COOLER PIPING (#65001-)
COOLING SYSTEM, OIL COOLER PIPING (#65001-)
c002013
COOLING SYSTEM, FAN MOTOR PIPING (#65018-)
COOLING SYSTEM, FAN MOTOR PIPING (#65018-)
c002012
COOLING SYSTEM, FAN MOTOR PIPING (#65001-65017)
COOLING SYSTEM, FAN MOTOR PIPING (#65001-65017)
c002011
COOLING SYSTEM, PIPING (#65001-)
COOLING SYSTEM, PIPING (#65001-)
c002015
COOLING SYSTEM, SUB-TANK (#65001-)
COOLING SYSTEM, SUB-TANK (#65001-)
c002016
COOLING SYSTEM, AFTERCOOLER PIPING (#65001-)
COOLING SYSTEM, AFTERCOOLER PIPING (#65001-)
c002017

COOLING SYSTEM, COVER AND SENSOR (#65001-)

PC800-8E0 S/N 65001-UP
36
36
37
37
34
12
13
35
27
29
26
31
33
32
14
16
25
24
34
8
4
3
17
18
1
5
7
6
2
11
35
9
10
33
32
28
18
17
22
25
24
15
23
20
21
19
30
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
1.   7861-93-3520   [1]   Sensor, Temperature Komatsu OEM 0.12 кг.
    ["SN: 65001-UP"]
2.   209-03-42111   [1]   Bracket Komatsu China
    ["SN: 65001-UP"] analogs:["2090342111XC"]
3.   01010-81225   [1]   Bolt Komatsu 0.074 кг.
    ["SN: 65001-UP"] analogs:["01010B1225", "0101051225", "0101051222", "R0101081225"]
4.   01643-31232   [1]   Washer Komatsu 0.027 кг.
    ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
5.   08193-20012   [1]   Clip Komatsu 0.012 кг.
    ["SN: 65001-UP"]
8.   209-03-41620   [1]   Cover Komatsu China
    ["SN: 65001-UP"]
9.   01010-81230   [2]   Bolt Komatsu 0.043 кг.
    ["SN: 65001-UP"] analogs:["0101051230", "01010B1230"]
11.   02896-11009   [2]   O-ring Komatsu China 0.01 кг.
    ["SN: 65001-UP"] analogs:["R0289611009", "0286911009"]
12.   01010-81650   [8]   Bolt Komatsu China 0.113 кг.
    ["SN: 65001-UP"] analogs:["0101061650", "0101051650", "0101031650"]
13.   01643-31645   [8]   Washer Komatsu 0.072 кг.
    ["SN: 65001-UP"] analogs:["802170005", "0164301645"]
14.   209-54-42372   [1]   Cover Komatsu China
    ["SN: 65001-UP"]
   15.   209-03-42141   [1]   Sheet Komatsu China
    ["SN: 65001-UP"]
   16.   209-03-42282   [1]   Sheet Komatsu China
    ["SN: 65001-UP"]
19.   209-03-42382   [1]   Cover Komatsu China
    ["SN: 65001-UP"]
   20.   209-03-42161   [1]   Sheet Komatsu China
    ["SN: 65001-UP"]
   21.   209-03-42180   [1]   Sheet Komatsu China
    ["SN: 65001-UP"]
   22.   209-03-42250   [1]   Sheet Komatsu China
    ["SN: 65001-UP"]
26.   209-03-42392   [1]   Cover Komatsu China
    ["SN: 65001-UP"]
   30.   209-03-77390   [2]   Sheet Komatsu China
    ["SN: 65001-UP"]
34.   209-03-41630   [2]   Cover Komatsu China
    ["SN: 65001-UP"] analogs:["2090341630XC"]
   35.   209-03-42260   [1]   Sheet Komatsu China
    ["SN: 65001-UP"]
