COOLING SYSTEM, RADIATOR, AFTERCOOLER AND OIL COOLER (#65001-)
39
40
41
39
40
41
42
44
43
1
1
1
16
11
12
17
18
18
17
13
14
15
19
20
22
23
25
27
26
3
2
29
28
32
34
34
34
34
29
28
32
34
34
34
34
29
28
33
30
31
34
34
34
34
8
7
7
4
8
10
9
5
6
36
36
37
37
37
37
38
38
38
38
38
38
38
38
36
36
35
21
24
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 209-03-41210 | [3] | Radiator Core Assembly Komatsu | 43 кг. |
| ["SN: 65001-UP"] | ||||
| 2. | 209-03-41280 | [6] | Cushion Komatsu | 0.1 кг. |
| ["SN: 65001-UP"] | ||||
| 3. | 22B-03-12590 | [6] | Cushion Komatsu | 0.04 кг. |
| ["SN: 65001-UP"] | ||||
| 4. | 209-03-41310 | [6] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 5. | 01010-81030 | [12] | Bolt Komatsu OEM | 0.03 кг. |
| ["SN: 65001-UP"] analogs:["801015110", "M018011000306", "YM26116100302", "0101051030"] | ||||
| 6. | 01643-31032 | [12] | Washer Komatsu | 0.054 кг. |
| ["SN: 65001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] | ||||
| 7. | 21T-03-32440 | [24] | Cushion Komatsu | 0.12 кг. |
| ["SN: 65001-UP"] | ||||
| 8. | 207-03-75590 | [24] | Plate Komatsu | 0.07 кг. |
| ["SN: 65001-UP"] | ||||
| 9. | 01010-81060 | [12] | Bolt Komatsu | 0.126 кг. |
| ["SN: 65001-UP"] analogs:["0101051060"] | ||||
| 11. | 209-03-41252 | [1] | Bracket Komatsu China | |
| ["SN: 65069-UP"] | ||||
| 11. | 209-03-41251 | [1] | Bracket Komatsu | 33.23 кг. |
| ["SN: 65001-65068", "SCC: A2"] | ||||
| 12. | 209-03-41262 | [1] | Bracket Komatsu China | |
| ["SN: 65069-UP"] | ||||
| 12. | 209-03-41261 | [1] | Bracket Komatsu China | |
| ["SN: 65001-65068", "SCC: A2"] | ||||
| 13. | 209-03-41271 | [1] | Bracket Komatsu China | |
| ["SN: 65069-UP"] | ||||
| 13. | 209-03-41270 | [1] | Bracket Komatsu China | |
| ["SN: 65001-65068", "SCC: A2"] | ||||
| 14. | 01010-81230 | [4] | Bolt Komatsu | 0.043 кг. |
| ["SN: 65001-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 15. | 01643-31232 | [4] | Washer Komatsu | 0.027 кг. |
| ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 16. | 209-03-41230 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 17. | 01010-81240 | [8] | Bolt Komatsu | 0.052 кг. |
| ["SN: 65001-UP"] analogs:["801015573", "0101051240"] | ||||
| 19. | 209-03-41240 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 22. | 209-03-41290 | [1] | Plate Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 25. | 209-03-41221 | [1] | Tank Komatsu China | |
| ["SN: 65001-UP"] analogs:["2090341220"] | ||||
| 28. | 209-03-42310 | [3] | Tube Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 29. | 209-03-42320 | [3] | Gasket Komatsu | 0.01 кг. |
| ["SN: 65001-UP"] | ||||
| 32. | 209-03-41340 | [2] | Hose Komatsu | 0.4 кг. |
| ["SN: 65001-UP"] | ||||
| 33. | 209-03-41330 | [1] | Hose Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 34. | 07289-00055 | [12] | Clamp Komatsu | 0.058 кг. |
| ["SN: 65001-UP"] analogs:["802660176"] | ||||
| 35. | 14X-03-11140 | [1] | Cap Komatsu | 0.25 кг. |
| ["SN: 65001-UP"] | ||||
| 36. | 209-03-41350 | [4] | Sheet Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 37. | 209-03-41360 | [4] | Sheet Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 38. | 209-03-41380 | [8] | Sheet Komatsu | 0.007 кг. |
| ["SN: 65001-UP"] | ||||
| 39. | 209-03-41110 | [2] | Oil Cooler Komatsu | 51 кг. |
| ["SN: 65001-UP"] | ||||
| 40. | 01010-81025 | [16] | Bolt Komatsu | 0.36 кг. |
| ["SN: 65001-UP"] analogs:["0101051025", "0101651025", "801015109"] | ||||
| 42. | 209-03-41121 | [1] | Aftercooler Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 43. | 01010-81235 | [4] | Bolt Komatsu | 0.048 кг. |
| ["SN: 65001-UP"] analogs:["0101051235", "01010E1235", "801015136"] | ||||
