COOLING SYSTEM, RADIATOR AND OIL COOLER MOUNTING (#65048-)
5
4
3
14
13
8
6
7
11
12
7
6
8
11
12
1
1
3
2
1
1
2
4
5
1
1
6
8
9
13
14
15
10
8
6
15
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 209-03-42710 | [8] | Cushion Komatsu | 0.25 кг. |
| ["SN: 65001-UP"] | ||||
| 2. | 209-03-42720 | [4] | Plate Komatsu China | |
| ["SN: 65001-UP"] analogs:["2090342720SG"] | ||||
| 3. | 209-03-42730 | [8] | Collar Komatsu | 0.23 кг. |
| ["SN: 65001-UP"] | ||||
| 4. | 01011-81600 | [8] | Bolt Komatsu | 0.188 кг. |
| ["SN: 65001-UP"] analogs:["0101161600", "801014198", "0101151600", "0101131600"] | ||||
| 5. | 01643-31645 | [8] | Washer Komatsu | 0.072 кг. |
| ["SN: 65001-UP"] analogs:["802170005", "0164301645"] | ||||
| 6. | 566-54-12212 | [4] | Cushion Komatsu | 0.25 кг. |
| ["SN: 65001-UP"] | ||||
| 7. | 569-03-12190 | [2] | Bushing Komatsu China | |
| ["SN: 65001-UP"] analogs:["4305425610"] | ||||
| 8. | 565-54-12841 | [4] | Washer Komatsu | 0.2 кг. |
| ["SN: 65001-UP"] | ||||
| 9. | 209-03-41560 | [1] | Bracket Komatsu China | |
| ["SN: 65048-UP"] | ||||
| 10. | 209-03-41570 | [1] | Bracket Komatsu China | |
| ["SN: 65048-UP"] | ||||
| 11. | 01011-81610 | [2] | Bolt Komatsu | 0.204 кг. |
| ["SN: 65048-UP"] analogs:["0101161610"] | ||||
| 13. | 01010-81250 | [4] | Bolt Komatsu | 0.061 кг. |
| ["SN: 65048-UP"] analogs:["0101051250"] | ||||
| 14. | 01643-31232 | [4] | Washer Komatsu | 0.027 кг. |
| ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 15. | 41L-971-1221 | [2] | Plate Komatsu China | |
| ["SN: 65001-UP"] analogs:["41L9711220"] | ||||
