GREASE PUMP, INNER PARTS, GREASE PUMP (#65001-)
13
10
11
12
7
14
15
16
6
5
3
2
1
4
19
20
18
17
9
8
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 21M-98-11110 | [1] | Pump Assembly, Grease Komatsu | 14 кг. | |
| ["SN: 65001-UP"] |$0. | ||||
| 1. | YU682481-4 | [1] | Adapter Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 2. | YU802584-4 | [1] | Valve Kit, Spring Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 3. | YU710915-3 | [1] | Lid Komatsu China | |
| ["SN: 65001-UP"] analogs:["YU8311624"] | ||||
| 4. | YU790713-4 | [1] | Name Plate Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 5. | YU683122-4 | [2] | Plug Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 6. | YU683347-4 | [6] | Screw Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 7. | YU802649-2 | [1] | Cover Assembly Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 8. | YU682789 | [1] | Switch Komatsu | 0.04 кг. |
| ["SN: 65001-UP"] | ||||
| 9. | YU683108 | [1] | Box Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 9. | YU682052 | [1] | Fuse Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 10. | YU851835-2 | [1] | Pump Assembly, Grease Komatsu | 9.26 кг. |
| ["SN: 65001-UP"] | ||||
| 11. | YU602296-1 | [3] | Screw Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 12. | YU631418-1 | [4] | Washer Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 13. | YU610623-1 | [3] | Bolt Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 14. | YU803085-4 | [1] | Plate Assembly Komatsu | 0.94 кг. |
| ["SN: 65001-UP"] | ||||
| 15. | YU707937-4 | [1] | Holder Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 16. | YU602298-1 | [1] | Screw Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 17. | YU707880-4 | [1] | Washer Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 18. | YU701930-4 | [1] | Washer Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 19. | 08055-00292 | [1] | Connector Body Assembly, Female Komatsu | 0.009 кг. |
| ["SN: 65001-UP"] | ||||
| 20. | YU681900A4 | [1] | Nipple Komatsu China | |
| ["SN: 65001-UP"] | ||||
