GREASE PUMP, INNER PARTS, REEL (#65001-)
4
2
1
2
1
3
26
15
35
9
12
9
8
21
36
24
22
19
18
23
18
19
20
17
34
9
8
14
13
9
8
11
10
27
7
25
16
6
5
31
29
28
33
13
14
30
32
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 209-68-51241 | [1] | Hose Reel Assembly Komatsu | 28.167 кг. | |
| ["SN: 65001-UP"] |$0. | ||||
| 1. | YU770199-4 | [2] | Stopper Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 2. | YU702062-4 | [2] | Band Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 3. | YU619154-0 | [2] | Bolt Komatsu China | |
| ["SN: 65001-UP"] analogs:["YU6191551"] | ||||
| 4. | YU627012-1 | [2] | Nut Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 5. | YU707944-4 | [1] | Spring Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 6. | YU707942-4 | [1] | Stopper Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 7. | YU707954-3 | [1] | Cam, Stopper Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 8. | YU681677-4 | [11] | Bolt Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 9. | YU631418-1 | [12] | Washer Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 10. | YU619073-0 | [2] | Bolt Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 11. | YU631417-1 | [2] | Washer Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 12. | YU790372-4 | [1] | Label Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 13. | YU619145-0 | [4] | Bolt Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 14. | YU631420-1 | [4] | Washer Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 15. | YU831174-3 | [1] | Plate Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 16. | YU640006-0 | [1] | O-ring Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 17. | YU709484-4 | [1] | Holder Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 18. | YU640020-0 | [2] | O-ring Komatsu | 0.001 кг. |
| ["SN: 65001-UP"] | ||||
| 19. | YU643680-0 | [2] | Ring Komatsu | 0.01 кг. |
| ["SN: 65001-UP"] | ||||
| 20. | YU705893-4 | [1] | Washer Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 21. | YU630695-0 | [1] | Retainer Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 22. | YU708673-4 | [1] | Adapter Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 23. | YU708831-4 | [1] | Swivel Joint Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 24. | YU770951-4 | [1] | Packing Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 25. | YU708832-4 | [1] | Bearing Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 26. | YU680109-4 | [2] | Adapter Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 27. | YU708833-3 | [1] | Arm Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 28. | YU831089-2 | [1] | Drum Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 29. | YU708834-4 | [1] | Bracket Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 30. | YU790371-4 | [1] | Label Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 31. | YU708835-3 | [1] | Arm Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 32. | YU708671-4 | [1] | Bearing Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 33. | YU801941-4 | [1] | Spring Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 34. | YU627010-1 | [1] | Nut Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 35. | YU611095-1 | [1] | Bolt Komatsu China | |
| ["SN: 65001-UP"] | ||||
| 36. | YU708830-4 | [1] | Stopper Komatsu China | |
| ["SN: 65001-UP"] | ||||
