ARM CYLINDER, R.H. (#65001-) PC850-8E0 S/N 65001-UP Komatsu


OK. Запрос отправлен.
EXCAVATORS
PC850-8E0 S/N 65001-UP
ARM CYLINDER
ARM CYLINDER, L.H. (#65001-)
ARM CYLINDER, L.H. (#65001-)
t004001

ARM CYLINDER, R.H. (#65001-)

PC850-8E0 S/N 65001-UP
30
29
6
7
7
8
2
13
32
19
14
32
18
31
15
21
26
9
10
11
10
22
23
16
25
34
48
12
27
33
30
29
47
4
4
1
3
45
46
20
5
28
49
24
50
43
17
51
42
41
37
35
38
39
36
38
39
36
42
41
40
44
41
42
51
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
     707-01-0AS40   [1]   Cylinder Assembly Komatsu China
    ["SN: 65001-UP"] |$0.
   1.   721-13-18210   [1]   Cylinder Komatsu China
    ["SN: 65001-UP"]
   2.   707-58-12810   [1]   Rod Komatsu China
    ["SN: 65001-UP"]
   3.   707-76-11130   [1]   Bushing Komatsu China 2.52 кг.
    ["SN: 65001-UP"]
   4.   07145-00110   [2]   Seal, Dust, (Kit : K07) Komatsu 0.054 кг.
    ["SN: 65001-UP"]
   5.   07043-00108   [1]   Plug, Taper Komatsu 0.005 кг.
    ["SN: 65001-UP"] analogs:["0704320108", "0704350108", "820510607", "YM23871010000", "R0704300108"]
   9.   707-71-32940   [1]   Collar Komatsu 6.022 кг.
    ["SN: 65001-UP"]
   10.   707-35-91840   [2]   Ring, Back-up, (Kit : K07) Komatsu 0.013 кг.
    ["SN: 65001-UP"]
   11.   07000-15175   [1]   O-ring, (Kit : K07) Komatsu China 0.03 кг.
    ["SN: 65001-UP"] analogs:["0700005175"]
   12.   707-71-61330   [1]   Plunger Komatsu China
    ["SN: 65001-UP"]
   13.   707-71-70330   [1]   Plunger Komatsu China
    ["SN: 65001-UP"]
   14.   04260-00952   [11]   Ball Komatsu 0.004 кг.
    ["SN: 65001-UP"] analogs:["890001277"]
   15.   707-71-91230   [1]   Cap Komatsu 0.011 кг.
    ["SN: 65001-UP"]
   16.   707-27-18930   [1]   Head, Cylinder Komatsu China
    ["SN: 65001-UP"]
   17.   707-56-12740   [1]   Seal, Dust, (Kit : K07) Komatsu China
    ["SN: 65001-UP"]
   18.   07179-13136   [1]   Ring, Snap Komatsu 0.029 кг.
    ["SN: 65001-UP"]
   19.   707-51-12030   [1]   Packing, Rod, (Kit : K07) Komatsu China 0.08 кг.
    ["SN: 65001-UP"]
   20.   707-51-12650   [1]   Ring, Buffer, (Kit : K07) Komatsu China
    ["SN: 65001-UP"]
   21.   707-52-90981   [1]   Bushing Komatsu 0.331 кг.
    ["SN: 65001-UP"] analogs:["7075290980"]
   24.   07179-13126   [1]   Ring, Snap Komatsu 0.027 кг.
    ["SN: 65001-UP"]
   25.   01011-82400   [12]   Bolt Komatsu OEM 0.462 кг.
    ["SN: 65001-UP"] analogs:["0101162400", "0101152400", "0101132400"]
   26.   707-88-75410   [12]   Washer Komatsu 0.035 кг.
    ["SN: 65001-UP"]
   27.   707-36-18520   [1]   Piston Komatsu 12.45 кг.
    ["SN: 65001-UP"]
   28.   707-44-18250   [1]   Ring, Piston, (Kit : K07) Komatsu China
    ["SN: 65001-UP"]
   29.   707-39-18510   [2]   Ring, Wear, (Kit : K07) Komatsu 0.123 кг.
    ["SN: 65001-UP"]
   30.   707-44-18920   [2]   Ring Komatsu OEM 0.12 кг.
    ["SN: 65001-UP"]
   31.   07000-B5110   [1]   O-ring, (Kit : K07) Komatsu 0.014 кг.
    ["SN: 65001-UP"]
   32.   07001-05110   [2]   Ring, Back-up, (Kit : K07) Komatsu 0.008 кг.
    ["SN: 65001-UP"]
   33.   01310-01225   [1]   Screw Komatsu 0.02 кг.
    ["SN: 65001-UP"] analogs:["0131021225"]
34.   707-86-00410   [1]   Tube Komatsu China
    ["SN: 65001-UP"]
35.   707-88-50890   [1]   Bracket Komatsu China
    ["SN: 65001-UP"]
36.   707-88-26620   [2]   Band Komatsu China
    ["SN: 65001-UP"]
37.   707-88-50900   [1]   Bracket Komatsu China
    ["SN: 65001-UP"]
38.   07372-21250   [8]   Bolt Komatsu 0.055 кг.
    ["SN: 65001-UP"] analogs:["0737201250"]
39.   01643-51232   [8]   Washer Komatsu 0.024 кг.
    ["SN: 65001-UP"]
40.   07371-51260   [2]   Flange, Split Komatsu 0.4 кг.
    ["SN: 65001-UP"]
41.   01010-81245   [8]   Bolt Komatsu 0.056 кг.
    ["SN: 65001-UP"] analogs:["0101051245", "801015574"]
42.   01643-31232   [8]   Washer Komatsu 0.027 кг.
    ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
43.   707-88-33040   [1]   Cap Komatsu 0.02 кг.
    ["SN: 65001-UP"]
44.   707-88-33050   [1]   Cap Komatsu China
    ["SN: 65001-UP"]
45.   07000-13035   [1]   O-ring, (Kit : K07) Komatsu China 0.03 кг.
    ["SN: 65001-UP"] analogs:["0700003035"]
46.   07372-21035   [4]   Bolt Komatsu 0.033 кг.
    ["SN: 65001-UP"]
47.   01643-51032   [4]   Washer Komatsu 0.17 кг.
    ["SN: 65001-UP"] analogs:["R0164351032"]
48.   07372-21060   [4]   Bolt Komatsu 0.045 кг.
    ["SN: 65001-UP"] analogs:["0737251060"]
50.   07371-31049   [2]   Flange, Split Komatsu 0.12 кг.
    ["SN: 65001-UP"] analogs:["0737121049"]
51.   707-88-10150   [2]   Clamp Komatsu 0.32 кг.
    ["SN: 65001-UP"]
