ARM, BUCKET CYLINDER PIPING (#65001-)
5
5
2
3
4
1
3
4
2
5
1
5
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 07098-21219 | [2] | Hose, Flange Type Komatsu China | 11.365 кг. |
| ["SN: 65001-UP"] | ||||
| 2. | 07371-51260 | [8] | Flange, Split Komatsu | 0.4 кг. |
| ["SN: 65001-UP"] | ||||
| 3. | 01010-81245 | [16] | Bolt Komatsu | 0.056 кг. |
| ["SN: 65001-UP"] analogs:["0101051245", "801015574"] | ||||
| 4. | 01643-31232 | [16] | Washer Komatsu | 0.027 кг. |
| ["SN: 65001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 5. | 07000-13038 | [4] | O-ring Komatsu China | 0.03 кг. |
| ["SN: 65001-UP"] analogs:["0700213038"] | ||||
