STEERING CASE FRAME
1
2
2
3
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 196-21-34100 | [1] | CASE ASS'Y Komatsu China | |
| ["SN: 14263-UP"] | ||||
| 2. | 07044-13620 | [3] | PLUG Komatsu | 0.496 кг. |
| ["SN: 14263-UP"] analogs:["0704403620"] | ||||
| 3. | 07002-43634 | [3] | O-RING Komatsu | 1.58 кг. |
| ["SN: 14263-UP"] analogs:["0700253634"] | ||||
| 4. | 07040-14220 | [2] | PLUG Komatsu | 0.325 кг. |
| ["SN: 14263-UP"] analogs:["0704114212"] | ||||
| 5. | 07002-44234 | [2] | O-RING Komatsu | 0.04 кг. |
| ["SN: 14263-UP"] analogs:["0700254234"] | ||||
| 6. | 07350-00215 | [2] | NIPPLE Komatsu | 0.25 кг. |
| ["SN: 14263-UP"] | ||||
| 7. | 07030-00252 | [2] | BREATHER Komatsu | 0.09 кг. |
| ["SN: 14263-UP"] analogs:["R0703000252"] | ||||
| 8. | 195-21-11321 | [1] | PLATE Komatsu China | |
| ["SN: 14263-UP"] | ||||
| 9. | 01010-80816 | [5] | BOLT Komatsu | 0.022 кг. |
| ["SN: 14263-UP"] analogs:["0101050816", "801015084"] | ||||
| 10. | 01643-30823 | [5] | WASHER Komatsu | 0.004 кг. |
| ["SN: 14263-UP"] analogs:["802070008", "802150008", "0160510818", "0164310823", "802170001", "01643A0823"] | ||||
| 12. | 195-21-11242 | [1] | COVER Komatsu China | |
| ["SN: 14263-UP"] | ||||
| 13. | 01580-11210 | [5] | NUT Komatsu | 0.03 кг. |
| ["SN: 14263-UP"] analogs:["801703210", "801920106"] | ||||
| 14. | 01643-31232 | [5] | WASHER Komatsu | 0.027 кг. |
| ["SN: 14263-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 15. | 195-21-12380 | [1] | O-RING Komatsu | 0.061 кг. |
| ["SN: 14263-UP"] | ||||
| 16. | 195-21-11172 | [1] | GASKET Komatsu | 0.13 кг. |
| ["SN: 14263-UP"] | ||||
| 17. | 01010-81855 | [20] | BOLT Komatsu | 0.16 кг. |
| ["SN: 14263-UP"] analogs:["0101061855", "0101031855"] | ||||
| 18. | 01643-31845 | [20] | WASHER Komatsu China | 0.02 кг. |
| ["SN: 14263-UP"] analogs:["0164321845", "R0164331845"] | ||||
| 19. | 195-15-11330 | [1] | PIN Komatsu China | |
| ["SN: 14263-UP"] | ||||
