FRONT IDLER (COLD WEATHER (B) SPEC.)
1
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
12
13
13
14
15
16
16
17
17
18
18
19
20
20
21
21
22
22
22
23
23
24
25
25
26
26
27
27
28
28
29
29
30
30
31
31
32
32
33
33
34
34
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 196-30-00133 | [2] | FRONT IDLER ASS'Y Komatsu China | 640 кг. | |
| ["SN: 14263-UP"] analogs:["1953001470", "1953000057", "1953000051", "1953000059", "1953000055", "1953000280", "1953000282", "1953000470", "1953000054", "1953000058", "1953013390", "1953000056", "1953000053", "1953000284", "1953013353", "1953000351", "1953000052", "1953061510", "1953001170", "1953013351", "1953013352", "1953000281", "1963000031", "1963000032", "1963000131", "1963000132", "1953013354", "1953000283", "1953001471"] |$1. | ||||
| 1. | 195-30-13354 | [1] | IDLER Komatsu China | 640 кг. |
| ["SN: 14263-UP"] analogs:["1953001470", "1953000057", "1953000051", "1953000059", "1953000055", "1953000280", "1953000282", "1953000470", "1953000054", "1953000058", "1953013390", "1953000056", "1953000053", "1953000284", "1953013353", "1953000351", "1953000052", "1953061510", "1953001170", "1953013351", "1953013352", "1953000281", "1963000133", "1963000031", "1963000032", "1963000131", "1963000132", "1953000283", "1953001471"] | ||||
| 2. | 195-30-13251 | [1] | SHAFT Komatsu | 35.75 кг. |
| ["SN: 14263-UP"] | ||||
| 3. | 195-30-13204 | [2] | BUSHING ASS'Y Komatsu | 11.8 кг. |
| ["SN: 14263-UP"] analogs:["1953013203", "1953013202", "1953013332", "1963016300"] | ||||
| 4. | 195-30-13280 | [2] | PIN Komatsu | 0.033 кг. |
| ["SN: 14263-UP"] | ||||
| 5. | 07000-45140 | [2] | O-RING Komatsu China | 0.015 кг. |
| ["SN: 14263-UP"] | ||||
| 6. | 01010-81245 | [16] | BOLT Komatsu | 0.056 кг. |
| ["SN: 14263-UP"] analogs:["0101051245", "801015574"] | ||||
| 7. | 01602-21236 | [16] | WASHER,SPRING Komatsu | 0.006 кг. |
| ["SN: 14263-UP"] analogs:["M011601200006", "0160211236"] | ||||
| 195-30-00203 | [2] | FLOATING SEAL ASS'Y Komatsu | 0.67 кг. | |
| ["SN: 14263-UP"] analogs:["1953000201", "1953000202", "1953018143"] |$9. | ||||
| 10. | 195-30-13431 | [2] | GUIDE ASS'Y,L.H. Komatsu | 32.7 кг. |
| ["SN: 14263-UP"] analogs:["1953013430", "1953013441"] | ||||
| 11. | 195-30-13164 | [1] | PLATE,R.H. (WELDED) Komatsu | 0.9 кг. |
| ["SN: 14263-UP"] | ||||
| 12. | 04020-01638 | [2] | PIN,DOWEL Komatsu | 0.064 кг. |
| ["SN: 14263-UP"] | ||||
| 13. | 195-30-18290 | [2] | O-RING Komatsu China | 0.01 кг. |
| ["SN: 14263-UP"] | ||||
| 14. | 196-30-13110 | [1] | SUPPORT Komatsu China | 50 кг. |
| ["SN: 14263-UP"] | ||||
| 15. | 196-30-13120 | [1] | SUPPORT Komatsu China | 50.5 кг. |
| ["SN: 14263-UP"] | ||||
| 16. | 175-30-23170 | [2] | BOLT Komatsu | 0.33 кг. |
| ["SN: 14263-UP"] | ||||
| 17. | 175-30-23180 | [2] | NUT Komatsu | 0.056 кг. |
| ["SN: 14263-UP"] | ||||
| 18. | 01643-31645 | [2] | WASHER Komatsu | 0.072 кг. |
| ["SN: 14263-UP"] analogs:["802170005", "0164301645"] | ||||
| 19. | 07052-31624 | [1] | PLUG Komatsu | 0.076 кг. |
| ["SN: 14263-UP"] analogs:["0705211624", "0705221624"] | ||||
| 20. | 195-30-13470 | [2] | PLATE Komatsu China | |
| ["SN: 14263-UP"] | ||||
| 21. | 195-30-13480 | [4] | BOLT Komatsu | 0.34 кг. |
| ["SN: 14263-UP"] | ||||
| 22. | 01643-32060 | [4] | WASHER Komatsu China | 0.044 кг. |
| ["SN: 14263-UP"] analogs:["802170007", "0164322045", "0164302045"] | ||||
| 23. | 195-30-13490 | [2] | BOLT Komatsu | 0.208 кг. |
| ["SN: 14263-UP"] | ||||
| 25. | 175-30-05050 | [2] | SHIM KIT Komatsu | 0.156 кг. |
| ["SN: 14263-UP"] | ||||
| 26. | 175-30-05060 | [2] | SHIM KIT Komatsu | 0.32 кг. |
| ["SN: 14263-UP"] | ||||
| 27. | 195-30-17960 | [12] | PLATE Komatsu China | 0.12 кг. |
| ["SN: 14263-UP"] | ||||
| 28. | 155-30-13230 | [12] | SPRING Komatsu China | 0.7 кг. |
| ["SN: 14263-UP"] | ||||
| 29. | 195-30-17942 | [4] | PLATE Komatsu China | 2.927 кг. |
| ["SN: 14263-UP"] | ||||
| 30. | 195-30-05040 | [2] | SHIM KIT Komatsu | 1.3 кг. |
| ["SN: 14263-UP"] | ||||
| 31. | 195-30-13213 | [2] | PLATE Komatsu | 19.1 кг. |
| ["SN: 14263-UP"] | ||||
| 32. | 01011-82465 | [8] | BOLT Komatsu | 9.808 кг. |
| ["SN: 14263-UP"] analogs:["0101132465", "0101152465", "0101162465"] | ||||
| 33. | 01602-22472 | [8] | WASHER Komatsu China | 0.044 кг. |
| ["SN: 14263-UP"] | ||||
| 34. | 195-30-13510 | [4] | SEAT Komatsu | 2.026 кг. |
| ["SN: 14263-UP"] | ||||
