TRACK SHOE (860MM) (SINGLE GROUSER)
1
2
3
3
4
5
6
7
8
9
10
10
11
12
12
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 196-32-01009 | [1] | TRACK SHOE ASS'Y Komatsu China | 4335 кг. | |
| ["SN: 14263-UP"] analogs:["1963201001", "1963201003", "1963201005", "1963201008", "1963201006", "1963201000"] |$1. | ||||
| 1. | 195-32-11127 | [84] | LINK Komatsu | 11 кг. |
| ["SN: 14263-UP"] analogs:["1953211126", "1953211125"] | ||||
| 2. | 195-32-11137 | [84] | LINK Komatsu | 12.46 кг. |
| ["SN: 14263-UP"] analogs:["1953211136", "1953211135"] | ||||
| 3. | 195-32-22221 | [320] | WASHER Komatsu | 0.05 кг. |
| ["SN: 14263-UP"] | ||||
| 4. | 195-32-22170 | [4] | BUSHING Komatsu China | 5.7 кг. |
| ["SN: 14263-UP"] | ||||
| 5. | 195-32-22141 | [80] | BUSHING Komatsu | 6.28 кг. |
| ["SN: 14263-UP"] | ||||
| 6. | 195-32-22151 | [80] | PIN Komatsu | 6.393 кг. |
| ["SN: 14263-UP"] analogs:["1953222150", "1953222151E"] | ||||
| 7. | 196-32-11111 | [84] | SHOE,TRACK Komatsu China | 64.9 кг. |
| ["SN: 14263-UP"] analogs:["1963211112", "1963211110"] | ||||
| 8. | 209-32-11234 | [336] | BOLT Komatsu China | 0.000 кг. |
| ["SN: 14263-UP"] | ||||
| 9. | 195-32-11222 | [336] | NUT Komatsu OEM | 0.24 кг. |
| ["SN: 14263-UP"] | ||||
| 11. | 209-32-11391 | [4] | PIN, MASTER Komatsu | 6.454 кг. |
| ["SN: 14263-UP"] analogs:["1953222190", "1953222191"] | ||||
| 12. | 195-32-22231 | [8] | SPACER Komatsu | 0.33 кг. |
| ["SN: 14263-UP"] | ||||
