TRACK FRAME D355C-3 S/N 14263-UP (SA6D140-2 Eng. Installed (-50cent. Spec.)) Komatsu


OK. Запрос отправлен.
PIPELAYERS
D355C-3 S/N 14263-UP (SA6D140-2 Eng. Installed (-50cent. Spec.))
UNDER CARRIAGE
TRACK SHOE (1010MM) (SINGLE GROUSER)
TRACK SHOE (1010MM) (SINGLE GROUSER)
300060
TRACK SHOE (960MM) (SINGLE GROUSER)
TRACK SHOE (960MM) (SINGLE GROUSER)
300050
TRACK SHOE (860MM) (SINGLE GROUSER)
TRACK SHOE (860MM) (SINGLE GROUSER)
300040
RECOIL SPRING
RECOIL SPRING
300080
TRACK FRAME COVER
TRACK FRAME COVER
300090
TRACK ROLLER GUARD
TRACK ROLLER GUARD
300100

TRACK FRAME

D355C-3 S/N 14263-UP (SA6D140-2 Eng. Installed (-50cent. Spec.))
1
2
3
4
5
6
7
8
9
10
10
10
11
11
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
27
27
28
28
28
29
30
31
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
     196-30-00143   [1]   TRACK FRAME ASS'Y,L.H. Komatsu 1789.46 кг.
    ["SN: 14263-UP"] |$3.
   1.   196-30-21112   [1]   TRACK FRAME,L.H. Komatsu China
    ["SN: 14263-UP"]
2.   195-30-11253   [2]   PLATE (WELDED) Komatsu China
    ["SN: 14263-UP"]
3.   195-30-11290   [2]   PLATE (WELDED) Komatsu 5.5 кг.
    ["SN: 14263-UP"]
4.   195-30-17912   [2]   PLATE (WELDED) Komatsu China
    ["SN: 14263-UP"] analogs:["1953017910"]
   5.   07040-13016   [1]   PLUG Komatsu 0.171 кг.
    ["SN: 14263-UP"]
   6.   07002-43034   [1]   O-RING Komatsu 1.34 кг.
    ["SN: 14263-UP"] analogs:["0700253034"]
   7.   195-30-12214   [1]   GUARD,L.H. Komatsu 20.6 кг.
    ["SN: 14263-UP"] analogs:["1953012212"]
   8.   195-30-12224   [1]   GUARD,R.H. Komatsu 20.9 кг.
    ["SN: 14263-UP"]
   9.   195-30-12193   [1]   GUARD,L.H. Komatsu China 24.7 кг.
    ["SN: 14263-UP"] analogs:["1953012192", "1953012191"]
   10.   01010-82250   [12]   BOLT Komatsu 0.231 кг.
    ["SN: 14263-UP"] analogs:["0101062250", "0101052250", "0101032250"]
   11.   01643-32260   [12]   WASHER Komatsu China 0.042 кг.
    ["SN: 14263-UP"]
12.   19N-30-11380   [1]   GUARD,L.H. Komatsu China
    ["SN: 14263-UP"]
15.   196-30-31320   [1]   STEP Komatsu China
    ["SN: 14263-UP"]
16.   01010-81640   [3]   BOLT Komatsu 0.264 кг.
    ["SN: 14263-UP"] analogs:["0101061640", "801015186", "0101031640", "0101051640"]
17.   01643-31645   [3]   WASHER Komatsu 0.072 кг.
    ["SN: 14263-UP"] analogs:["802170005", "0164301645"]
18.   196-30-31310   [1]   TRACK FRAME,R.H. Komatsu China
    ["SN: 14263-UP"]
26.   195-30-12233   [1]   GUARD,R.H. Komatsu China 24.45 кг.
    ["SN: 14263-UP"]
29.   19N-30-11390   [1]   GUARD,R.H. Komatsu 13.35 кг.
    ["SN: 14263-UP"]
