PPC VALVE D355C-3 S/N 14263-UP (SA6D140-2 Eng. Installed (-50cent. Spec.)) Komatsu


OK. Запрос отправлен.
PIPELAYERS
D355C-3 S/N 14263-UP (SA6D140-2 Eng. Installed (-50cent. Spec.))
SERVICE KIT AND COMPONENT PARTS
HYDRAULIC TANK AND CONTROL VALVE
HYDRAULIC TANK AND CONTROL VALVE
450100
COUNTER WEIGHT CYLINDER (COLD WEATHER (B) SPEC.)(#14413-)
COUNTER WEIGHT CYLINDER (COLD WEATHER (B) SPEC.)(#14413-)
450090
COUNTER WEIGHT CYLINDER(#14263-14412)
COUNTER WEIGHT CYLINDER(#14263-14412)
450080
SLOW RETURN VALVE
SLOW RETURN VALVE
450120
HIGH-LOW SELECT VALVE
HIGH-LOW SELECT VALVE
450130
COMPRESSOR(#14413-14648)
COMPRESSOR(#14413-14648)
450140

PPC VALVE

D355C-3 S/N 14263-UP (SA6D140-2 Eng. Installed (-50cent. Spec.))
1
2
2
3
3
4
4
5
5
5
6
7
7
8
8
9
9
10
10
11
11
12
13
14
14
15
15
16
16
17
17
18
19
20
21
22
23
24
25
26
27
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
     702-11-17002   [1]   VALVE ASS'Y Komatsu 45 кг.
    ["SN: 14263-UP"] analogs:["7021117001", "7021117000"] |$1.
   3.   702-11-11190   [6]   PISTON Komatsu China
    ["SN: 14263-UP"]
   4.   702-11-17150   [6]   SHAFT Komatsu China
    ["SN: 14263-UP"]
   5.   702-11-17160   [10]   RETAINER Komatsu China
    ["SN: 14263-UP"]
   6.   702-11-11280   [4]   SPRING Komatsu China
    ["SN: 14263-UP"]
   7.   702-11-11320   [6]   SPRING Komatsu China
    ["SN: 14263-UP"]
   8.   702-11-11330   [6]   GUIDE Komatsu China
    ["SN: 14263-UP"]
   9.   702-11-11231   [6]   RING,SNAP Komatsu China
    ["SN: 14263-UP"] analogs:["7021111230"]
   10.   702-11-17140   [6]   GUIDE Komatsu China
    ["SN: 14263-UP"]
   11.   702-11-17210   [2]   PLATE Komatsu China
    ["SN: 14263-UP"]
   12.   01010-80816   [6]   BOLT Komatsu 0.022 кг.
    ["SN: 14263-UP"] analogs:["0101050816", "801015084"]
   13.   702-11-17250   [4]   COLLAR Komatsu China
    ["SN: 14263-UP"]
   14.   702-11-17240   [6]   SPRING Komatsu 0.003 кг.
    ["SN: 14263-UP"]
   15.   07002-53034   [6]   O-RING Komatsu 1.34 кг.
    ["SN: 14263-UP"] analogs:["0700243034"]
   16.   702-11-17230   [6]   PLUG Komatsu China
    ["SN: 14263-UP"]
   17.   702-11-17220   [2]   PLATE Komatsu China
    ["SN: 14263-UP"]
   18.   702-11-17181   [1]   GASKET Komatsu 0.018 кг.
    ["SN: 14263-UP"]
   19.   702-11-17130   [1]   COVER Komatsu China
    ["SN: 14263-UP"]
   20.   01010-81025   [10]   BOLT Komatsu 0.36 кг.
    ["SN: 14263-UP"] analogs:["0101051025", "0101651025", "801015109"]
   21.   01010-81070   [5]   BOLT Komatsu 0.054 кг.
    ["SN: 14263-UP"] analogs:["0101051070"]
   22.   702-11-17310   [1]   GASKET Komatsu 0.02 кг.
    ["SN: 14263-UP"]
   23.   702-11-17320   [1]   COVER Komatsu China
    ["SN: 14263-UP"]
   25.   702-11-17260   [2]   RETAINER Komatsu China
    ["SN: 14263-UP"]
   26.   702-11-17270   [2]   COLLAR Komatsu China
    ["SN: 14263-UP"]
   27.   07042-30108   [1]   PLUG Komatsu 0.008 кг.
    ["SN: 14263-UP"] analogs:["0704220108"]
