EQUALIZER BAR(#10601-10684) D475A-3 S/N 10601-UP (Shoe Slipping Control Spec.) Komatsu


OK. Запрос отправлен.
BULLDOZERS
D475A-3 S/N 10601-UP (Shoe Slipping Control Spec.)
MAIN FRAME AND RELATED PARTS
MAIN FRAME
MAIN FRAME
210010
EQUALIZER BAR(#10685-)
EQUALIZER BAR(#10685-)
210030
PIVOT SHAFT (FOR DUAL TILT PITCH DOZER)
PIVOT SHAFT (FOR DUAL TILT PITCH DOZER)
210040
PIVOT SHAFT
PIVOT SHAFT
210050

EQUALIZER BAR(#10601-10684)

D475A-3 S/N 10601-UP (Shoe Slipping Control Spec.)
1
2
2
3
3
4
5
5
6
6
7
8
8A
9
10
11
12
13
14
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
49
50
50
51
52
53
53
54
  For full view, you need register

Parts on group :

Pos. Part No Qty Parts name Comments
     198-50-00110   [1]   EQUALIZER BAR ASS'Y Komatsu 650 кг.
    ["SN: 10601-10684"] analogs:["1985000114", "1985000111"] |$3.
   1.   198-50-51111   [1]   BAR Komatsu China
    ["SN: 10601-@"] analogs:["1985051113", "1985051114"]
   2.   198-50-51131   [2]   BUSHING Komatsu 9.4 кг.
    ["SN: 10601-@"]
   3.   198-50-11171   [2]   SEAL,DUST Komatsu 0.03 кг.
    ["SN: 10601-@"]
   4.   198-50-51161   [2]   BUSHING Komatsu 15.1 кг.
    ["SN: 10601-@"]
   5.   198-50-51170   [4]   SEAL Komatsu 0.58 кг.
    ["SN: 10601-@"]
   6.   198-50-51380   [4]   RING Komatsu 0.94 кг.
    ["SN: 10601-@"]
   7.   04071-00200   [2]   RING,SNAP Komatsu 0.2 кг.
    ["SN: 10601-@"]
   8.   07020-00000   [4]   FITTING,GREASE Komatsu China 0.006 кг.
    ["SN: 10601-@"] analogs:["YM24761020000", "1756731361", "860010009", "070200000", "R0702000000", "0700000000"]
   8A.   07043-70108   [2]   PLUG Komatsu 0.005 кг.
    ["SN: 10601-10684"] analogs:["07043A0108"]
9.   198-50-51120   [1]   PIN Komatsu 76.4 кг.
    ["SN: 10601-@"]
10.   198-50-42540   [1]   LOCK Komatsu 3.5 кг.
    ["SN: 10601-@"]
11.   01010-82455   [4]   BOLT Komatsu 0.31 кг.
    ["SN: 10601-@"] analogs:["01010B2455", "0101052455", "0101032455", "0101062455"]
12.   01643-32460   [4]   WASHER Komatsu China 0.063 кг.
    ["SN: 10601-@"] analogs:["R0164332460"]
13.   07049-03645   [1]   PLUG Komatsu China
    ["SN: 10601-@"]
14.   198-50-51180   [4]   BUSHING Komatsu 2 кг.
    ["SN: 10601-10684"]
15.   198-50-51150   [2]   SHAFT Komatsu 40.3 кг.
    ["SN: 10601-10684"]
16.   198-50-51360   [1]   COVER,L.H. Komatsu China
    ["SN: 10601-10684"]
17.   198-50-51370   [1]   COVER,R.H. Komatsu China
    ["SN: 10601-10684"]
18.   07000-02020   [2]   O-RING Komatsu OEM 0.001 кг.
    ["SN: 10601-@"]
19.   198-50-51350   [2]   SEAL Komatsu 0.12 кг.
    ["SN: 10601-10684"]
20.   01010-82055   [8]   BOLT Komatsu China 0.202 кг.
    ["SN: 10601-10684"] analogs:["0101062055", "0101052055", "0101032055"]
21.   01643-32060   [8]   WASHER Komatsu China 0.044 кг.
    ["SN: 10601-@"] analogs:["802170007", "0164322045", "0164302045"]
23.   198-50-51312   [1]   COVER,L.H Komatsu China
    ["SN: 10601-10684"]
24.   198-50-51322   [1]   COVER,R.H Komatsu China
    ["SN: 10601-10684"]
25.   01010-81630   [4]   BOLT Komatsu 0.081 кг.
    ["SN: 10601-10684"] analogs:["0101061630", "0101051630", "0101031630"]
26.   01643-31645   [4]   WASHER Komatsu 0.072 кг.
    ["SN: 10601-10684"] analogs:["802170005", "0164301645"]
27.   198-50-51280   [2]   COVER Komatsu 0.06 кг.
    ["SN: 10601-10684"]
28.   195-50-41290   [4]   PLATE Komatsu China
    ["SN: 10601-10684"]
29.   01010-80825   [8]   BOLT Komatsu 0.015 кг.
    ["SN: 10601-10684"] analogs:["0101050825", "01010D0825", "801015087"]
30.   01602-20825   [8]   WASHER Komatsu 0.004 кг.
    ["SN: 10601-10684"] analogs:["0160200825", "0231011020", "6124613790"]
31.   198-50-51240   [2]   STOPPER Komatsu 6 кг.
    ["SN: 10601-10684"]
32.   04022-12045   [4]   PIN,DOWEL Komatsu 0.041 кг.
    ["SN: 10601-10684"]
33.   198-50-51261   [1]   COVER,L.H Komatsu China
    ["SN: 10601-10684"]
34.   198-50-51271   [1]   COVER,R.H Komatsu China
    ["SN: 10601-10684"]
35.   01010-82045   [6]   BOLT Komatsu 0.178 кг.
    ["SN: 10601-10684"] analogs:["0101062045", "0101052045", "0101032045"]
37.   198-50-51291   [1]   BRACKET Komatsu China
    ["SN: 10601-@"]
38.   01010-81225   [2]   BOLT Komatsu 0.074 кг.
    ["SN: 10601-@"] analogs:["01010B1225", "0101051225", "0101051222", "R0101081225"]
39.   01643-31232   [2]   WASHER Komatsu 0.027 кг.
    ["SN: 10601-@"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"]
40.   07020-00675   [1]   FITTING Komatsu China 0.011 кг.
    ["SN: 10601-@"] analogs:["21D0989220", "37A099G004"]
41.   203-62-21740   [1]   NIPPLE Komatsu 0.02 кг.
    ["SN: 10601-@"]
42.   175-54-35330   [1]   HOSE Komatsu China
    ["SN: 10601-@"]
43.   198-904-4280   [3]   CLIP Komatsu 0.02 кг.
    ["SN: 10601-@"]
44.   01010-81016   [3]   BOLT Komatsu 0.06 кг.
    ["SN: 10601-@"] analogs:["0101051016"]
45.   01643-31032   [3]   WASHER Komatsu 0.054 кг.
    ["SN: 10601-@"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"]
46.   202-62-21430   [1]   ELBOW Komatsu 0.04 кг.
    ["SN: 10601-@"]
47.   198-50-51331   [1]   TUBE,L.H Komatsu China
    ["SN: 10601-10684"]
48.   198-50-51341   [1]   TUBE,R.H Komatsu China
    ["SN: 10601-10684"]
49.   07213-50710   [2]   CONNECTOR Komatsu 0.022 кг.
    ["SN: 10601-@"]
50.   566-16-11970   [4]   CLIP Komatsu 0.01 кг.
    ["SN: 10601-10684"]
51.   01010-81020   [4]   BOLT Komatsu 0.161 кг.
    ["SN: 10601-10684"] analogs:["801014093", "0101051020", "801015108"]
53.   20D-68-11780   [2]   ELBOW Komatsu 0.08 кг.
    ["SN: 10601-10684"]
