PIVOT SHAFT (FOR DUAL TILT PITCH DOZER)
1
1
2
2
3
3
4
4
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
13
13
14
14
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 198-50-52111 | [2] | SHAFT Komatsu | 365 кг. |
| ["SN: 10601-UP"] | ||||
| 2. | 198-30-34170 | [34] | BOLT Komatsu | 0.869 кг. |
| ["SN: 10601-UP"] | ||||
| 3. | 207-46-52130 | [34] | WASHER Komatsu | 0.191 кг. |
| ["SN: 10601-UP"] | ||||
| 4. | 07049-03342 | [6] | PLUG Komatsu China | |
| ["SN: 10601-UP"] analogs:["1502111120"] | ||||
| 5. | 198-50-52231 | [2] | COVER Komatsu | 19.72 кг. |
| ["SN: 10601-UP"] | ||||
| 6. | 198-50-31251 | [2] | SEAL Komatsu | 4.8 кг. |
| ["SN: 10601-UP"] | ||||
| 7. | 01010-81640 | [12] | BOLT Komatsu | 0.264 кг. |
| ["SN: 10601-UP"] analogs:["0101061640", "801015186", "0101031640", "0101051640"] | ||||
| 8. | 01643-31645 | [12] | WASHER Komatsu | 0.072 кг. |
| ["SN: 10601-UP"] analogs:["802170005", "0164301645"] | ||||
| 9. | 07000-05190 | [2] | O-RING Komatsu | 0.022 кг. |
| ["SN: 10601-UP"] analogs:["0700015190"] | ||||
| 10. | 198-50-31270 | [2] | SPACER Komatsu | 2.308 кг. |
| ["SN: 10601-UP"] | ||||
| 11. | 01011-82005 | [20] | BOLT Komatsu | 0.322 кг. |
| ["SN: 10601-UP"] analogs:["0101162005"] | ||||
| 12. | 01643-32060 | [20] | WASHER Komatsu China | 0.044 кг. |
| ["SN: 10601-UP"] analogs:["802170007", "0164322045", "0164302045"] | ||||
| 13. | 01010-81665 | [6] | BOLT Komatsu | 0.134 кг. |
| ["SN: 10601-UP"] analogs:["0101051665", "0101031665", "0101061665", "R0101081665"] | ||||
