OIL COOLER (MAIN PIPING)
1
2
3
4
5
6
7
8
8
9
10
11
11
12
12
13
14
15
16
17
18
18
19
19
20
21
22
23
24
25
26
27
27
28
29
30
30
31
32
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 01010-81245 | [2] | BOLT Komatsu | 0.056 кг. |
| ["SN: 30001-UP"] analogs:["0101051245", "801015574"] | ||||
| 2. | 01643-51232 | [2] | WASHER Komatsu | 0.024 кг. |
| ["SN: 30001-UP"] | ||||
| 5. | 198-03-62750 | [1] | PLATE Komatsu China | |
| ["SN: 30001-UP"] | ||||
| 6. | 01010-81230 | [2] | BOLT Komatsu | 0.043 кг. |
| ["SN: 30001-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 7. | 01643-31232 | [2] | WASHER Komatsu | 0.027 кг. |
| ["SN: 30001-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 8. | 07283-34354 | [2] | CLIP Komatsu | 0.118 кг. |
| ["SN: 30001-UP"] | ||||
| 9. | 01643-31032 | [4] | WASHER Komatsu | 0.054 кг. |
| ["SN: 30001-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] | ||||
| 10. | 01597-01009 | [4] | NUT Komatsu | 0.011 кг. |
| ["SN: 30001-UP"] | ||||
| 11. | 01010-81240 | [4] | BOLT Komatsu | 0.052 кг. |
| ["SN: 30001-UP"] analogs:["801015573", "0101051240"] | ||||
| 15. | 07371-31465 | [2] | FLANGE Komatsu | 0.28 кг. |
| ["SN: 30001-UP"] | ||||
| 16. | 07372-21240 | [4] | BOLT Komatsu | 0.052 кг. |
| ["SN: 30001-UP"] analogs:["0737201240"] | ||||
| 18. | 198-61-44220 | [4] | CLAMP Komatsu | 0.36 кг. |
| ["SN: 30001-UP"] | ||||
| 19. | 198-61-44130 | [2] | CUSHION Komatsu China | |
| ["SN: 30001-UP"] | ||||
| 20. | 198-43-15310 | [1] | COLLAR, 10MM Komatsu China | |
| ["SN: 30102-UP"] | ||||
| 21. | 01011-81200 | [1] | BOLT Komatsu | 0.104 кг. |
| ["SN: 30102-UP"] analogs:["801015583", "0101151200"] | ||||
| 22. | 01011-81205 | [1] | BOLT Komatsu | 0.108 кг. |
| ["SN: 30102-UP"] | ||||
| 24. | 198-33-12380 | [1] | WASHER Komatsu | 0.041 кг. |
| ["SN: 30102-UP"] | ||||
| 25. | 07000-73045 | [1] | O-RING Komatsu China | 0.002 кг. |
| ["SN: 30001-UP"] analogs:["R0700073045"] | ||||
| 26. | 198-03-73250 | [1] | TUBE Komatsu China | |
| ["SN: 30001-UP"] | ||||
| 28. | 198-03-73241 | [1] | TUBE Komatsu China | |
| ["SN: 30001-UP"] | ||||
| 29. | 198-03-62731 | [1] | HOSE Komatsu China | 3.75 кг. |
| ["SN: 30001-UP"] | ||||
| 30. | 07000-73048 | [2] | O-RING Komatsu OEM | 0.01 кг. |
| ["SN: 30001-UP"] analogs:["0700063048", "R0700073048"] | ||||
| 31. | 198-03-62790 | [1] | HOSE Komatsu China | 5 кг. |
| ["SN: 30001-UP"] | ||||
