TRACK FRAME (R.H.)
1
2
2
3
4
4
5
6
7
8
9
10
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 156-30-00070 | [1] | TRACK FRAME G.,R.H. Komatsu China | ||
| ["SN: 36551-UP"] |$2. | ||||
| 1. | 156-30-21120 | [1] | TRACK FRAME,R.H. Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 2. | 154-30-41140 | [2] | PLATE Komatsu | 2.3 кг. |
| ["SN: 36551-UP"] | ||||
| 3. | 154-30-41150 | [2] | PLATE Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 4. | 154-30-41220 | [2] | GUARD Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 5. | 154-30-41230 | [1] | GUARD Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 6. | 155-30-11390 | [2] | PLATE Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 7. | 154-30-12540 | [1] | CAP,R.H. Komatsu | 8 кг. |
| ["SN: 36551-UP"] | ||||
| 8. | 01011-82410 | [1] | BOLT Komatsu | 0.497 кг. |
| ["SN: 36551-UP"] analogs:["0101162410", "0101152410", "0101132410"] | ||||
| 9. | 01011-82450 | [1] | BOLT Komatsu | 0.635 кг. |
| ["SN: 36551-UP"] analogs:["801015695", "0101152450", "0101162450"] | ||||
| 10. | 01643-32460 | [2] | WASHER Komatsu China | 0.063 кг. |
| ["SN: 36551-UP"] analogs:["R0164332460"] | ||||
| 11. | 156-30-21220 | [1] | COVER,R.H. Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 12. | 01010-81230 | [5] | BOLT Komatsu | 0.043 кг. |
| ["SN: 36551-UP"] analogs:["0101051230", "01010B1230"] | ||||
| 13. | 01643-31232 | [5] | WASHER Komatsu | 0.027 кг. |
| ["SN: 36551-UP"] analogs:["0164371232", "0164381232", "802170003", "R0164331232", "0614331232"] | ||||
| 14. | 156-30-21240 | [1] | COVER A.,R.H. Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 156-30-21260 | [1] | COVER,R.H. Komatsu China | ||
| ["SN: 36551-UP"] |$18. | ||||
| 15. | 154-30-27180 | [1] | BOLT Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 16. | 01590-11215 | [1] | NUT Komatsu | 0.02 кг. |
| ["SN: 36551-UP"] analogs:["0159021215", "0159001215", "0159031215"] | ||||
| 17. | 01641-21223 | [1] | WASHER Komatsu | 0.005 кг. |
| ["SN: 36551-UP"] analogs:["0164101223"] | ||||
| 18. | 04050-13025 | [1] | PIN,COTTER Komatsu | 0.01 кг. |
| ["SN: 36551-UP"] | ||||
| 19. | 01010-81225 | [4] | BOLT Komatsu | 0.074 кг. |
| ["SN: 36551-UP"] analogs:["01010B1225", "0101051225", "0101051222", "R0101081225"] | ||||
| 21. | 01010-81235 | [4] | BOLT Komatsu | 0.048 кг. |
| ["SN: 36551-UP"] analogs:["0101051235", "01010E1235", "801015136"] | ||||
| 23. | 156-30-21280 | [1] | COVER,R.H. Komatsu China | |
| ["SN: 36551-UP"] | ||||
