ELECTRICAL ENGINE HEATER (SPECIAL ORDER)
1
2
3
3
4
4
5
6
7
8
9
10
11
12
13
14
14
14
15
16
17
18
19
20
21
For full view, you need register
Parts on group :
| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 154-06-42540 | [1] | WIRING HARNESS Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 2. | 195-06-22810 | [1] | BRACKET Komatsu China | |
| ["SN: 37828-UP"] | ||||
| 3. | 01220-40312 | [4] | SCREW Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 4. | 01601-20307 | [4] | WASHER Komatsu China | |
| ["SN: 36551-UP"] analogs:["802150503", "PZF802150503", "PZF801150503", "38510161961"] | ||||
| 5. | 01010-81225 | [2] | BOLT Komatsu | 0.074 кг. |
| ["SN: 37828-UP"] analogs:["01010B1225", "0101051225", "0101051222", "R0101081225"] | ||||
| 5. | 01010-51225 | [2] | BOLT Komatsu | 0.074 кг. |
| ["SN: 36551-37827"] analogs:["0101081225", "01010B1225", "0101051222"] | ||||
| 6. | 01602-21236 | [2] | WASHER Komatsu | 0.006 кг. |
| ["SN: 36551-UP"] analogs:["M011601200006", "0160211236"] | ||||
| 7. | 175-06-39830 | [1] | CAP Komatsu | 0.28 кг. |
| ["SN: 36551-UP"] | ||||
| 8. | 01220-40612 | [1] | SCREW Komatsu | 0.004 кг. |
| ["SN: 36551-UP"] | ||||
| 9. | 01602-20619 | [1] | WASHER Komatsu | 0.004 кг. |
| ["SN: 36551-UP"] analogs:["802150506"] | ||||
| 10. | 01641-20608 | [1] | WASHER Komatsu | 0.001 кг. |
| ["SN: 36551-UP"] analogs:["0164220608", "0164100608", "0164240608", "6110733520"] | ||||
| 11. | 04434-51712 | [1] | CLIP Komatsu | 0.02 кг. |
| ["SN: 36551-UP"] | ||||
| 12. | 01010-81220 | [1] | BOLT Komatsu | 0.032 кг. |
| ["SN: 37828-UP"] analogs:["0101051220"] | ||||
| 12. | 01010-51220 | [1] | BOLT Komatsu | 0.032 кг. |
| ["SN: 36551-37827"] analogs:["0101081220"] | ||||
| 14. | 04434-51010 | [3] | CLIP Komatsu | 0.014 кг. |
| ["SN: 36551-UP"] | ||||
| 15. | 08053-01510 | [1] | CLIP Komatsu | 0.112 кг. |
| ["SN: 36551-UP"] | ||||
| 17. | 01010-81020 | [1] | BOLT Komatsu | 0.161 кг. |
| ["SN: 37828-UP"] analogs:["801014093", "0101051020", "801015108"] | ||||
| 17. | 01010-51020 | [1] | BOLT Komatsu | 0.161 кг. |
| ["SN: 36551-37827"] analogs:["0101081020", "801014093", "801015108"] | ||||
| 18. | 01643-31032 | [1] | WASHER Komatsu | 0.054 кг. |
| ["SN: 36551-UP"] analogs:["802150510", "0164331030", "0164381032", "0164371032", "0164331022", "0164321032", "0164301032", "6127212530", "802170002", "R0164331032"] | ||||
| 20. | 195-98-14750 | [1] | PLATE, CAUTION Komatsu China | |
| ["SN: 36551-UP"] | ||||
| 21. | 175-06-37871 | [1] | PLUG Komatsu | 0.25 кг. |
| ["SN: 36551-UP"] | ||||
